COBRA concept benefits
  • Plant is pre-installed and tested in factory before shipping
    • Fast installation and start up at the site
    • Can be moved within a very short time
    • All winter equipment and aggregate heating system ready installed and does not need to be dismantled when moving the plant
  • Suitable for on-site production, shotcrete, RMC and concrete for prefab purposes
  • Low cost transport and only little foundation works
  • Fast installation and quick start-up
 COBRA C80 technical features
  • "Flying" aggregate dosing and weighing system
  • Integrated control room and additive storage
  • Production capacity up to 80 m3/h (105 yd3/h)
  • 3 - 6 aggregate bins with very low and short loading ramp
  • 2 m3 (2,6 yd3) countercurrent planetary mixer
  • Binder material (cement, micro silica and fly ash) silos 1 - 5 pc.
  • Very compact construction
Optional equipment
  • Automatic fiber dosing system for steel and synthetic fibers
  • Steel frames as substructure and steel elements for the loading ramp to make plant as a super mobile concrete batching plant
  • Factory installed winter equipment for mixer room, control room, additive storage and aggregate bins
  • Powerful aggregate and water heating system operating with diesel or gas burner
  • Water chiller and ice flake plant

Additionally a wide range of optional equipment is available. Special models can be designed according to the customer’s requirements.

Watch the COBRA C80 concrete batch plant installation animation:
